防爆系列
PRODUCTS#FANWEI
· ⅡA、ⅡB、ⅡC类爆炸性气体环境的1区、2区场所；
· ⅢA、ⅢB、ⅢC类可燃性粉尘环境的21区、22区场所。
PRODUCTS#TEDIAN
· 铝合金压铸外壳，高压静电粉末喷涂，强度高，耐腐蚀；
· 凸面棱晶高强度钢化玻璃，照射范围广，出光均匀，无眩光。
PRODUCTS#JISHU
型号Type | AK-LBR25(LT) | AK-LBR25Y(LT) | AK-LBR35(LT) | AK-LBR45(LT) |
系统功率Power | 25W | 25W | 35W | 45W |
输入电压Input Voltage | AC110-264V 50-60Hz DC24/36V | |||
系统输出System Output | 2750lm | 2750lm | 3500lm | 4500lm |
系统光效System Luminous Efficency | ≥110lm/W | ≥110lm/W | ≥100lm/W | ≥100lm/W |
显色指数Color Rendering Index | ≥80 | |||
色温Color Temperature | 2700~6500K | |||
透明罩Transparent Cover | 高强度钢化玻璃 Tempered Glass | |||
进线口螺纹Cable Gland Thread | G3/4” | |||
电缆外径Cable External Diameter | 8~12mm | |||
防护等级Degree of Protection | IP66 | |||
防腐等级Degree of Corrosion-proof | WF2 | |||
防爆标志Ex-mark | Ex d ll C T6 GbEx tD A21 IP66 T80℃ | |||
重量Weight | 2.9kg | 3.5kg | 2.9kg | 2.9kg |
执行标准Implementing Standard | GB3836.1 GB3836.2 GB12476.1 GB12476.5 | |||
应急照明时间Emergency Lighting Time | - | ≥60min(≥30min) | - | - |
充电时间Charging Time | - | 10-12h | - | - |
充放电循环次数Charging Cycle Times | - | 500次 | - | - |
PRODUCTS#XUAN
序号 S/N | 型号Type | 功率 Power | 环境温度Environment Temperature | 应急Emergency |
1 | AK-LBR25 | 25W | -20℃～55℃ | - |
2 | AK-LBR25Y | 25W | -20℃～40℃ | √ |
3 | AK-LBR35 | 35W | -20℃～55℃ | - |
4 | AK-LBR45 | 45W | -20℃～40℃ | - |
5 | AK-LBR25-LT | 25W | -45℃～55℃ | - |
6 | AK-LBR25Y-LT | 25W | -45℃～40℃ | √ |
7 | AK-LBR35-LT | 35W | -45℃～55℃ | - |
8 | AK-LBR45-LT | 45W | -45℃～40℃ | - |
